Great for:
- Added functions with USB
- Ramp and soak applications
- 5 Programs, 4 Segments per program
- Display quality
- 50mA Pulse Output Can Drive Up To 4 Standard Solid State Relays
Typical uses:
- Replace West, Omron, Eurotherm
- Ovens and kilns (multiple ramp and soaks)
- Autoclaves
- Machinery and OEM
- Process equipment
- Heat treatment
- Metal processing
N1050 is an advanced high performance PID temperature controller featuring a vivid LCD display in a modern design package. It combines the proven robustness of NOVUS PID algorithm with a large and bright easy-to-read multicolor 11-segment LCD display with alphanumeric mnemonics and crystal clear status signaling.
Besides the PID auto-tuning capability, N1050 outputs PWM control mode through pulse or relay. Up to three optional output relays can be selected. It also features 5 ramp-and-soak profile programs, soft start output and timer function which complement the advanced features of the controller. With password protected, all parameters are configurable by the display menu, via USB port or optional RS485 Modbus interface.
Easy to install and maintain due to its detachable connector, N1050 offers the lowest power consumption in the market. Housed in anti-flame material, it has 48x48 mm (DIN 1/16) format and low profile front panel. Suitable for hostile environments, it complies with standard EMC regulations, providing robustness and reliability including untapped temperature applications.
MPN 8105000000 (AC)
Novus N1050-PR Datasheet Download
Novus N1050-PR Manual Download
Sample Configuration Files For QuickTune (.qtc)
Sample Configuration File PT100 Download
Sample Configuration File Type K Download
SIZE: 48 x 48 x 80 mm (1/16 DIN)
PANEL CUTOUT: 46 x 46 mm (+0.5 -0.0 mm)
SUPPLY: 100 to 240 Vac (±10 %), 50/60 Hz / 48 to 240 Vdc (±10 %)
INPUT: Thermocouples J; K; T; S and Pt100
OUTPUTS:
OUT1: Voltage pulse, 5 V / 50 mA
OUT2: ................................Relay SPST; 1.5 A / 240 Vac / 30 Vdc
OUT3: ................................Relay SPST; 1.5 A / 240 Vac / 30 Vdc
OUT4: ...................................Relay SPDT; 3 A / 240 Vac / 30 Vdc
